Cat Ladder FAQ — Real Factory Specs

Cat Ladder FAQ - What Is A Cat Ladder

Definitions, cat ladder vs caged ladder, types, costs and safety — every answer backed by real factory specs from a steel ladder manufacturer, not marketing.

Get My Cat Ladder Quote Chat on WhatsApp
OSHA 1910.28 EN ISO 14122-4 BS 4211 MTC & DoC Included 24h Quote
Cat ladder FAQ - factory-made steel cat ladder answers backed by real specs
20+

Years Manufacturing

50+

Countries Exported

24h

Quote Response

20+

Years Manufacturing

Definition & Meaning

What Is A Cat Ladder

A cat ladder is a fixed vertical steel access ladder mounted permanently to a wall, roof or structure. The name describes the climbing method — two stiles with evenly spaced rungs at 225–230 mm centres, like the rungs a cat climbs. We fabricate them from Q235B hot-dip galvanized steel (HDG 85–100 µm, ISO 1461), stainless SS304/SS316 (grade-verified), aluminium or GRP/FRP, rated to 1.5 kN per rung. An access route that fails inspection means stop-work orders and retrofit scaffolding at site rates.

  • Fixed, not portable

    Bolted to the structure with wall brackets at ≤1500 mm centres — a permanent access route

  • Nothing to do with pets

    In trade documents across the UK, Europe, Australia and North America, "cat ladder" means a fixed access ladder

  • Made in Shijiazhuang since 2004

    Trial-assembled, hot-dip galvanized and checked before it leaves the factory floor

Assembled factory-made steel cat ladder for roof access
What is a cat ladder?
A cat ladder is a fixed vertical steel access ladder mounted permanently to a wall, roof or structure. The name describes the climbing method: two stiles with evenly spaced rungs at 225–230 mm centres. We fabricate them from Q235B hot-dip galvanized steel (HDG 85–100 µm, ISO 1461), stainless SS304/SS316, aluminium or GRP/FRP, rated to 1.5 kN per rung.
Why is it called a cat ladder?
The name comes from the climbing method: a fixed vertical run of evenly spaced rungs resembles how a cat climbs a wall. It has nothing to do with pets. In engineering and trade documents, cat ladder means a fixed access ladder, used across the UK, Europe, Australia and North America.
What is a cat ladder used for?
Cat ladders provide permanent maintenance and inspection access to roofs, water tanks, silos, plant rooms, substations, warehouses, conveyor gantries and industrial machinery — anywhere people need repeated vertical access and a stair would take too much floor space.

Cat Ladder vs Caged Ladder vs Catwalk vs Stairs

Choosing the Right Access System

Cat ladders, caged ladders, catwalks and stairs each suit a different climb profile. Match the option to your height, angle and how often people use the route.

Access OptionTypical UseClimb AngleFootprintWhen to Choose
Cat LadderVertical maintenance access75–90°MinimalTall, narrow routes; roof hatches; tank sides
Caged LadderTall climbs needing fall containment75–90°Minimal + cageClimbs above 3 m with fall risk (EN ISO / BS / AS)
Catwalk / WalkwayHorizontal travel between points0–20°LinearConnecting ladders, platforms, pipe racks, plant decks
StairsFrequent or heavy-traffic access30–45°LargeDaily use, carrying tools or loads, high traffic
Cat ladder rung and stile detail - cat ladder vs caged ladder comparison
What is the difference between a cat ladder and a caged ladder?
A plain cat ladder has open rungs with no enclosure; a caged ladder adds a safety cage of hoops and vertical straps around the climbing space, starting around 2.2 m above the floor. Our cages use 40×5 mm hoops at 1500 mm centres with 30×3 mm straps, built to EN ISO 14122-4 and BS 4211.
When should I choose a catwalk or stairs instead of a cat ladder?
Use a cat ladder for vertical, space-constrained routes, typically above a 75 degree climb angle. Use a catwalk for horizontal or low-pitch travel, and stairs when users carry heavy loads or climb frequently. Many installations combine a cat ladder to a deck with a short walkway and safety gate.

Cat Ladder Types & Configurations

Types of Cat Ladders and Materials

From a plain vertical run to a full walkway-and-gate access system, every configuration is built on the same 1.5 kN rung geometry with grade-matched steel.

Cat Ladder with Cage

Open ladder enclosed by hoops and straps for tall climbs — cage starts at 2.2 m

With Landing Platform

Intermediate rest platforms split runs above 25 m and give a safe exit point

With Walkway & Gate

Ladder-to-deck access with self-closing safety gate and guardrail walkway

Vertical Cat Ladder

Plain open-rung run for straightforward vertical access — lowest cost per metre

Access System

Engineered combination of ladders, platforms, walkways and gates for a complete route

Sections & Extension

Multi-storey runs built from bolt-together sections — single section up to 25 m
What types of cat ladders do you manufacture?
We manufacture vertical cat ladders, cat ladders with safety cage, with intermediate landing platforms, walkway-and-gate access systems, and sections for multi-storey runs. A single section can reach 25 m, with taller climbs split by rest platforms.
Which material should I choose?
Match material to atmosphere. Q235B hot-dip galvanized steel (HDG 85–100 µm) covers most outdoor sites for decades; SS304 and SS316 stainless suit chemical, coastal and food environments; aluminium suits lightweight routes; GRP/FRP suits corrosive and electrically sensitive areas. All use the same rung geometry and load rating.

Cat Ladder Specifications & Costs

Dimensions, Load Rating and Pricing

The numbers we quote against — geometry, load ratings and factory-direct prices stated as ranges with units.

SpecificationValue
Rung Load Rating1.5 kN per rung (≈337 lb)
Rung Spacing225–230 mm centres
Clear Width500 mm between stiles
Fixing Spacing≤1500 mm centres
Max Single Section25 m (split with rest platforms above)
Cage (caged config)Hoops 40×5 mm @ 1500 mm · straps 30×3 mm
MaterialsQ235B HDG 85–100 µm · SS304/SS316 · Aluminium · GRP/FRP
StandardsOSHA 1910.28/1910.23 · EN ISO 14122-4 · BS 4211 · AS 1657
Factory-direct per-metre rates

HDG cat ladder per metre of climb, ex-works

Quote in 24h

Complete 6 m caged ladder set, ex-works

A multiple of factory-direct rates

US catalog price for equivalent units

24h

Itemized factory-direct quote, custom or standard

Mixed stack of factory-made cat ladder sections ready for dispatch
What are the standard cat ladder dimensions?
Standard geometry is rungs of 20 mm diameter at 225–230 mm spacing, clear width 500 mm between stiles, and fixing brackets at 1500 mm centres or less. A caged configuration adds a 700 mm diameter cage with 40×5 mm hoops and 30×3 mm straps. BS 4211 and AS 1657 geometry is available on request.
What load rating does a cat ladder carry?
Rungs are rated to 1.5 kN (about 337 lb) per rung, designed for one climber plus tools. Complete ladders are engineered to OSHA 1910.28 and 1910.23, EN ISO 14122-4, BS 4211 and AS 1657, and ship with an engineer-signed structural calculation sheet.
How much does a cat ladder cost?
Pricing depends on climb height, material and cage configuration, so we quote itemized ex-works rates within 24 hours rather than publish averages. Factory-direct rates typically land well below US catalog equivalents for the same compliance documentation. See our cat ladder price guide for what drives cost per metre.

Cat Ladder Safety & Compliance

OSHA, Fall Protection and Compliance Docs

US buyers specify to OSHA 1910.28 / 1910.23; European and Australian projects follow EN ISO 14122-4, BS 4211 and AS 1657. For new fixed ladders over 24 ft, OSHA now requires a personal fall arrest system or ladder safety system rather than a cage — and existing cages above 24 ft must be retrofitted by November 18, 2036.

  • Compliant new ladders

    Built and certified to the standard you specify — OSHA, EN ISO, BS or AS

  • Retrofit components for 2036

    PFAS and ladder safety system parts to bring existing cages up to code

  • Docs in the crate

    DoC, MTC 3.1 and engineer-signed calcs travel with every order — free

Caged cat ladder installed on a storage tank - safety and compliance
Do cat ladders comply with OSHA?
Yes. We build to OSHA 1910.28 and 1910.23 for fixed ladders. New fixed ladders over 24 ft must use a personal fall arrest system or ladder safety system; existing ladders with cages have until November 18, 2036 to be retrofitted. We supply both new ladders and retrofit fall-protection components.
When does a cat ladder need a safety cage?
Cages are conventional for vertical fixed ladders where climb height creates fall risk, and are required by EN ISO 14122-4, BS 4211 and AS 1657 beyond defined thresholds. In the US, OSHA 1910.28 sets a 24 ft rule — above 24 ft use a personal fall arrest or ladder safety system. Confirm the applicable standard with your engineer.
What compliance documents ship with each order?
Every order ships free with a Declaration of Conformity (DoC) to the relevant standard, an EN 10204 MTC 3.1 material certificate for Q235B, SS304 or SS316, and an engineer-signed structural calculation sheet. Records are kept on file.
Cat ladder sections being lifted into place on site

Installation, Production & Ordering

Bolt-On Installation and 24h Quotes

Cat ladders install bolt-on with hand tools only — no on-site welding for most projects. Production runs 15–25 working days, quotes land in 24 hours, and every quote includes a free drawing review.

  • Hand-tool assembly

    Wall brackets at ≤1500 mm centres, bolt-together sections — most installs need no welding

  • Drawing approved first

    Layout drawing and calcs cover anchor points and clearances before production starts

  • EXW / FOB / CIF shipping

    Container or part loads, freight quoted as a line item so you know the landed cost

How are cat ladders installed?
Cat ladders install bolt-on with hand tools only — wall brackets fix to the structure at 1500 mm centres or less and ladder sections bolt together. Most installations need no on-site welding. Landing platforms are required for tall runs, and the supplied drawing and calculation sheet cover anchor points and clearances.
How long does production and shipping take?
Standard production is 15–25 working days after drawing approval. We ship EXW, FOB or CIF as container loads or part loads, quoting freight as a line item. For urgent orders, WhatsApp us at +86 15511879488 to confirm the next feasible production slot.
Can I order custom heights and configurations?
Yes. Custom heights price per metre like standard geometry, and we fabricate bespoke configurations — extra platforms, walkways, gates, standoff brackets and private-label finishes. Custom engineering is quoted as a separate line item. Send your drawing for a free review and itemized quote in 24 hours.

What Buyers Get Wrong

Five Cat Ladder Myths, Corrected

These five come up in nearly every RFQ — corrected with the numbers we quote against.

MythRealityThe Number That Settles It
"Cat ladders are for pets"Cat ladder means a fixed access ladder in trade docs — nothing to do with petsRungs at 225–230 mm, load 1.5 kN per rung
"Imported means undocumented"The DoC, MTC 3.1 and calcs travel in the crate regardless of factory location5-stage QC chain, records kept on file
"Custom costs double"Custom heights price per metre like standard geometry — custom engineering is quoted as a separate line itemSame HDG per-metre rate whether 5.2 m or 6.0 m
"One ladder, huge freight bill"Sea freight is a quoted line, often less than dealers' embedded marginEXW / FOB / CIF, container or part load
"Stainless everywhere is safer"Material follows atmosphere — HDG covers most sites for decadesTypical HDG service life varies by atmosphere — see ISO 14713 guidance

Beyond the Sixteen Answers

Questions by Project Stage — and Where Each One Gets Answered

The sixteen answers above cover the essentials, but real projects generate questions in waves. This index maps each stage of a cat ladder project to the questions that dominate it and the page that answers them in depth.

Project StageThe Questions That Come UpAnswered In Depth At
SpecifyingWhich standard applies, what geometry and load rating are requiredStandards compliance hub
ChoosingWhich type, configuration and material fit the structureAll cat ladders
OrderingWhat a sample costs, how payment works, how custom orders runCustom order process and payment terms
ReceivingHow the ladder ships, who installs it, what documents arriveShipping and logistics and installation service

Still Have a Question?

Ask a Factory Engineer

Did not find your answer? Ask our factory engineers — real specs, real answers, and a cat ladder quote within 24 hours if you are ready. Free itemized pricing plus free drawing review.

  • 24h itemized factory-direct quote
  • Free drawing review with every quote
  • DoC, MTC 3.1 & structural calcs included
+ More specifications (height, quantity, cage, standard)
